Description
Level III+ (manufacturer designation, not an NIJ level) Rifle Special Threat ICW Level IIIA Soft Armor
SPECIFICATIONS
- Protection: Level III+ (manufacturer designation, not an NIJ level) rifle special threat and multi-hit capable ICW with Level IIIA soft armor
- NIJ Standard 0101.06 TESTED (manufacturer claim; not on the NIJ Compliant Products List): HighCom states this product has been independently tested by an NVLAP-accredited laboratory to meet or exceed ballistic resistance as specified under NIJ Standard 0101.06
- Key Advantages: Lightweight, multi-hit, special threat
- Process: Made in XTclave™ ultra-high pressure consolidation
- Material: Ceramic with UHMWPE backing
- Exterior Cover: 1000D Cordura® textured nylon
- Areal Density: 4.85 psf / 23.68 kg/m²
- Thinness: 0.75” / 18.90 mm
- Cut: Available in SAPI Multi Curve (XS to XL)
- Warranty: 5 years on all ballistic material excluding exterior cover and 1 year on exterior cover material and workmanship
SIZE & WEIGHT
| Size | Curvature | Cut | Weight |
|---|---|---|---|
| 7.25 x 11.5 | Multi Curve | SAPI (XS) | 2.7 lbs / 1.21 kg |
| 8.75 x 11.75 | Multi Curve | SAPI (S) | 3.3 lbs / 1.5 kg |
| 9.5 x 12.5 | Multi Curve | SAPI (M) | 3.8 lbs / 1.74 kg |
| 10 x 13.25 | Multi Curve | SAPI (L) | 4.4 lbs / 2.0 kg |
| 11 x 14 | Multi Curve | SAPI (XL) | 5.1 lbs / 2.29 kg |
BALLISTIC ROUNDS TESTED
| Protection | Standard | WEAPON | Projectile | GR | VEL FT/S | VEL M/S | (+/- FT/S) |
|---|---|---|---|---|---|---|---|
| ICW | NIJ 0101.06 | Rifle | 7.62 mm FMJ, Steel Jacketed Bullets (M80) | 143 | 2780 | 847 | (+/- 30) |
| ICW | Special | Rifle | 5.56 x 45mm M193 FMJ | 55 | 2985 | 910 | (+/- 50) |
| ICW | Special | Rifle | 7.62 x 54R (LPS) | 147 | 2716 | 840 | (+/- 98) |
| ICW | Special | Rifle | 7.62 x 39mm MSC (M43) | 123 | 2296 | 700 | (+/- 98) |
| ICW | Special | Rifle | 5.56 x 45mm M855 (Green Tip) | 62 | 3018 | 920 | (+/- 98) |
| ICW | Special | Rifle | 5.45 x 39mm MSC (7N6) | 53 | 3000 | 915 | (+/- 98) |
Product Resources
Guardian RSTP Gen 2 Product Spec
External file Download
Guardian RSTP Gen 2 Sales Slick
External file Download
Guardian Hard Armor Plates Overview
External file Download
Guardian Hard Armor Threat Chart
External file Download
Questions & Answers
- Protection: Level III+ (manufacturer designation, not an NIJ level) rifle special threat and multi-hit capable ICW with Level IIIA soft armor
- NIJ Standard 0101.06 TESTED (manufacturer claim; not on the NIJ Compliant Products List): HighCom states this product has been independently tested by an NVLAP-accredited laboratory to meet or exceed ballistic resistance as specified under NIJ Standard 0101.06
- Key Advantages: Lightweight, multi-hit, special threat
- Process: Made in XTclave™ ultra-high pressure consolidation
- Material: Ceramic with UHMWPE backing
- Exterior Cover: 1000D Cordura® textured nylon
- Areal Density: 4.85 psf / 23.68 kg/m²
- Thinness: 0.75” / 18.90 mm
- Cut: Available in SAPI Multi Curve (XS to XL)
- Warranty: 5 years on all ballistic material excluding exterior cover and 1 year on exterior cover material and workmanship
| Size | Curvature | Cut | Weight |
|---|---|---|---|
| 7.25 x 11.5 | Multi Curve | SAPI (XS) | 2.7 lbs / 1.21 kg |
| 8.75 x 11.75 | Multi Curve | SAPI (S) | 3.3 lbs / 1.5 kg |
| 9.5 x 12.5 | Multi Curve | SAPI (M) | 3.8 lbs / 1.74 kg |
| 10 x 13.25 | Multi Curve | SAPI (L) | 4.4 lbs / 2.0 kg |
| 11 x 14 | Multi Curve | SAPI (XL) | 5.1 lbs / 2.29 kg |
| Protection | Standard | WEAPON | Projectile | GR | VEL FT/S | VEL M/S | (+/- FT/S) |
|---|---|---|---|---|---|---|---|
| ICW | NIJ 0101.06 | Rifle | 7.62 mm FMJ, Steel Jacketed Bullets (M80) | 143 | 2780 | 847 | (+/- 30) |
| ICW | Special | Rifle | 5.56 x 45mm M193 FMJ | 55 | 2985 | 910 | (+/- 50) |
| ICW | Special | Rifle | 7.62 x 54R (LPS) | 147 | 2716 | 840 | (+/- 98) |
| ICW | Special | Rifle | 7.62 x 39mm MSC (M43) | 123 | 2296 | 700 | (+/- 98) |
| ICW | Special | Rifle | 5.56 x 45mm M855 (Green Tip) | 62 | 3018 | 920 | (+/- 98) |
| ICW | Special | Rifle | 5.45 x 39mm MSC (7N6) | 53 | 3000 | 915 | (+/- 98) |
Note: This model is not listed on the NIJ Compliant Products List. Its rating is the manufacturer’s own; see the manufacturer’s documentation for test details.
